Our Facilities Equipment List
Cad/Cam
- Solidworks Seats (6x)
- GibbsCAM Seats (15x)
- JobBoss Seats (11x)
Milling
- CNC Vertical (23x) – Capacity up to 32” (Y Axis) x 64” (X Axis) x 30” (Z Axis)
- CNC Vertical with 5th axis (8x)
- Conversational knee mills (5x)
- Manual Mill (1x)
Turning
- CNC Lathes (4x) - Capacity up to Ø24” x 60”
- CNC Lathes, with live tooling and sub spindles (7x) – Capacity up to Ø14” x 26”
- Swiss Lathe (3x) - Capacity up to Ø32mm
- Manual Lathes (2x) – Capacity up to Ø14” x 40”
EDM
- Wire EDM (7x) – Capacity up to 15.7” (Y Axis) x 23.6” (X Axis) x 16” (Z Axis)
- Wire EDM with 4th Axis Rotary (1x) – Capacity up to Ø3.94”
- EDM Hole Drill (1x)
- Sinker EDM- (1x) Capacity up to 17.7" (X Axis) x 11.8" (Y Axis) x 12.6" (Z Axis) with an 8 tool automatic changer
Welding
- Wire Feed Welder (3x) – Capability for Steel, Stainless & Aluminum
- Tig Welder (1x)
- Precision Welding Tables (2x)
- Acorn Welding Table (1x)
- Oxy/Acetylene Torch (1x)
Grind/Lap/Hone
- Automatic Surface Grinder (1x) – Capacity up to 12” x 24”
- Manual Surface Grinder (1x) – Capacity up to 6” x 12”
- Horizontal Hone (1x) – Capacity up to Ø.060” to Ø6.000”
- Lapping (2x) – Capacity up to Ø14.50”
Sawing
- Automatic Cutting Band Saw (2x) - Capacity up to Ø10.75”
- Mitre Band Saw (1x)
- Vertical Band Saw (2x) – Capacity up to 20”
Finishing
- Sand/Glass Bead blasting
- Tumbling
- Hand sanding, polishing and deburring
Inspection
- Coordinate Measuring Machines (4x) - Capacity up to 35.43” x 47.24” x 31.50”
- Vision Measuring System’s (2x) – Capacity up to 20” x 18” x 18”
- Portable Measuring Arm w/Laser Scanner- 8.2’ Measurement Volume
- Digital Height Gages (2x) – Capacity up to Ø28”
- Optical Comparator (2x)
- Micrometers - Capacity up to Ø12”
- Calipers - Capacity up to 60”
- Bore Gages - Capacity up to Ø6”
- Pin Gages - Capacity up to Ø1”
- Gage Blocks
- Thread/Ring Gages
- Profilometer
- Hardness Tester
Building Specs
- 44,000 Sq Ft Building
- 30,000 Sq Ft available expansion
- 44,000 Sq Ft Environmentally controlled
- Security Badge Entry
